Commercial and Residential

Safety and security window films

Safety and security films are constructed of thick polyester layers and highly aggressive adhesive in order to strengthen glass and hold onto shards when breakage occurs.

Anti-Intrusion Film In Action

Safety and security films delays intruders by acting as an anti intrusion barrier so occupants and alarm systems can respond to the threat

strengthening glass and holds shattered fragments together

Available in optically-clear color or tinted colors for solar protection

Natural disaster or accidental breaks will litter the space with dangerous shards of glass. Safety glass will splatter diamond-shaped pieces of glass across the space, impeding an evacuation during an emergency. Safety film is designed to hold shattered glass fragments and keep them within the window frame. Occupants are kept from flying glass while the weather remains outside.


Schools, daycares, hospitals, and many public facilities use safety films as a part of their earthquake preparedness program to keep their occupants safe from flying shards of glass.


Blast mitigation film is made to hold broken shards together while stretching as a blast wave passes, then rebound back during the negative phase of the blast. Glass fragments are the leading cause of injury and death during a terrorist attack or explosive event.


NOTE: 8mil security films do not pass anti-intrusion testing. 15mil thick films should be used for anti-intrusion purposes. Don't settle for less when life and property is being protected.


Anti-intrusion film surprises burglars by forcing them to use more aggressive break-in tactics to shatter the glass. In the mean time, the alarm sensor (glass breakage sensor) has triggered the alarm before the glass is even broken. Hopefully, this delay helps the police response while allowing occupants time to react to the threat.


This same window film technology is being used at schools to help slow down active shooters. Broken shards of glass being held in place by anti-intrusion window film inhibits access through the window frame while hindering the ability to sight targets through the shards. Retarding shooter progress through the building allows teachers, students, and the authorities time to act, warn, and respond.


Home and storefront burglaries are on the rise. Anti-intrusion window film is an invisible line of defense that slows the down the attack, allowing occupants to react, and protects assets.


EDGE ANCHORING - Highly recommended

Keeps the window pane in the frame longer

Keeps the window pane in the frame longer

Keeps the window pane in the frame longer

A thick bead of structural adhesive is applied along the edges of the film to affix it to the frame. Anchoring the film resists glass fall out, while keeping the weather outside of the building.

Better secures the building envelope

Keeps the window pane in the frame longer

Keeps the window pane in the frame longer

Home applications can receive a decorative paintable vinyl cap to compliment window frame finishes while concealing the structural adhesive edge anchoring bead underneath.

Downloads

Safety Shield 800 8mil Data Sheet (pdf)

Download

Safety Shield 1500 15mil Data Sheet (pdf)

Download

SafetyShield Testing Matrix 2-2018 (pdf)

Download

Wet Glaze Edge Anchoring (pdf)

Download
